Last week I was doing some performance tuning on SSAS Multidimensional and saw something very strange: when the MDX Script of the cube was executed (as always happens after the cache has been cleared, or processing has taken place – you can monitor this via the Execute MDX Script Begin/End events in Profiler) the Calculate() statement was taking just over four seconds. I’d never seen this before so I asked the nice people on the SSAS dev team what was going on, and Akshai Mirchandani very kindly filled me in on the details.

There are two types of calculation on an SSAS cube: those explicitly defined in the MDX Script (ie those seen on the Calculations tab of the cube editor); and semi-additive measures, unary operators and custom rollups, which are defined in the model itself. This second type of calculation is added to the cube when the Calculate() statement fires, and the more of them there are the longer it takes SSAS to work out where they should be applied in the space of the cube. In my customer’s case there were several large (80000+ members) parent/child hierarchies with unary operators as well as a few semi-additive measures and so this was the reason why Calculate() was so slow. Up to now I had only known that Calculate() triggers the aggregation of data up through the cube, which is why if you delete it the cube seems to contain no data.

Here’s something strange I came across today: a customer had created a calculated member, not on the measures dimension but on another hierarchy, and even though it had been selected in their client tool it wasn’t appearing in the query results. I tested in Excel and saw some strange error message. I was mystified, but after a bit of thought I found out what was going on…

Take the following query in Adventure Works:

WITH
MEMBER [Customer].[Gender].[CALC] AS 123
SELECT {[Measures].[Internet Sales Amount]} ON 0,
{[Customer].[Gender].&[F],
[Customer].[Gender].&[M],
[Customer].[Gender].[CALC]}
ON 1
FROM [Adventure Works]

When you run it, you get the results you would expect:

Now, if you change the calculated member name, you’ll see the problem that my customer was running into:

WITH
MEMBER [Customer].[Gender].[Gender] AS 123
SELECT {[Measures].[Internet Sales Amount]} ON 0,
{[Customer].[Gender].&[F],
[Customer].[Gender].&[M],
[Customer].[Gender].[Gender]}
ON 1
FROM [Adventure Works]

Instead of the calculated member, you now see Female and Male repeated twice. The reason why this is happening is down to how SSAS interprets the expression [Customer].[Gender].[Gender]. It’s the name of the calculated member that’s been defined, but it’s also the unique name of the Gender level on the Gender hierarchy of the Customer dimension:

As I explained in this blog post, when SSAS sees the unique name of a level it sticks the .MEMBERS function on the end and this returns the set of all members on the Gender level of the Gender hierarchy – and not the calculated member.

Of course, if you rewrite the query to use the ALLMEMBERS function as follows:

WITH
MEMBER [Customer].[Gender].[Gender] AS 123
SELECT {[Measures].[Internet Sales Amount]} ON 0,
[Customer].[Gender].ALLMEMBERS
ON 1
FROM [Adventure Works]

…you’ll see the calculated member returned:

So, the moral of this post is don’t create calculated members that have the same name as a level on a hierarchy. It’s unlikely that you’ll do this, but possible – in my customer’s case they had a hierarchy on a time utility dimension called “Periods To Date” and a calculated member on that hierarchy with the same name.

One of the many interesting things that caught my eye in the new SSAS Tabular Performance Tuning white paper is actually about new functionality in the SSAS 2012 Multidimensional and nothing to do with Tabular! It turns out that in the DAXMD release of SSAS 2012, ie SQL Server 2012 SP1 CU4, some work was done to enable the Formula Engine to cache the results of MDX calculations for longer than the lifetime of a query when a query includes a subselect. Here’s an excerpt from the paper:

Certain types of queries cannot benefit from MDX caching. For example, multi-select filters (represented in the MDX query with a subselect) prevent use of the global MDX formula engine cache. However, this limitation was lifted for most subselect scenarios as part of SQL Server 2012 SP1 CU4 (http://support.microsoft.com/kb/2833645/en-us). However, subselect global scope caching is still prevented for arbitrary shapes (http://blog.kejser.org/2006/11/16/arbitrary-shapes-in-as-2005/), transient calculations like NOW(), and queries without a dimension on rows or columns. If the business requirements for the report do not require visual totals and caching is not occurring for your query, consider changing the query to use a set in the WHERE clause instead of a subselect as this enables better caching in some scenarios.

This is a subject I’ve blogged about in the past, both for SSRS reports (which almost always use subselects in the MDX created by the query editor) and Excel PivotTables (which sometimes, but not always, use subselects) and you may want to read this posts to get some background. In my experience, if you have a lot of complex MDX calculations on your cube (financial applications are a great example), this issue can have a major impact on your overall query performance, even if it isn’t immediately obvious that this is the case. On builds of SSAS before 2012 SP1 CU4, even if Storage Engine caching is working properly, if a query references a lot of MDX calculations and includes a subselect it will be consistently slow however many times you run it because the calculations will need to be re-evaluated every time the query is run.

I’ve heard of a few problems with CU4 regarding SSRS so I don’t recommend upgrading your production SSAS servers just yet, but when these problems have been ironed out in the next full service pack I think this could be a compelling reason for many people to move to SSAS 2012. There’s also still a limitation whereby queries that return a single cell value and use a subselect may still not be able to use the global Formula Engine cache, but hopefully this will be dealt with in a future release too. Overall, though, I’m extremely pleased to see yet another improvement to the Multidimensional engine.

Thanks to Jeffrey Wang for answering my questions about this functionality.

One of the more popular blog posts from my archives (86 comments so far) is the one I wrote on “Counting New and Returning Customers in MDX”. The trouble with all of the calculations in there is that they execute in cell-by-cell mode, and therefore perform quite badly.

For example, take the following query on Adventure Works to find the number of returning customers (customers who have bought from us today and have also bought something before in the past):

with

member measures.[Returning Customers V1] as

count(

intersect(

nonempty([Customer].[Customer].[Customer].members, [Measures].[Internet Sales Amount])

,

nonempty([Customer].[Customer].[Customer].members,

    [Measures].[Internet Sales Amount] * {null : [Date].[Date].currentmember.prevmember})

)

)

select {measures.[Returning Customers V1]} on 0,

[Date].[Date].[Date].members

on 1

from

[Adventure Works]

On a cold cache this takes 47 seconds on my laptop and a quick look in Profiler shows this executes in cell-by-cell mode. In the comments on the original post Deepak Puri suggested an alternative approach using the Customer Count distinct count measure:

with

member measures.customerstodate as

aggregate(null:[Date].[Date].currentmember, [Measures].[Customer Count])

member measures.customerstoprevdate as

([Date].[Date].currentmember.prevmember, [Measures].customerstodate)

member measures.newcustomers as

measures.customerstodate - measures.customerstoprevdate

member measures.[Returning Customers V2] as

[Measures].[Customer Count] - measures.newcustomers

select {measures.[Returning Customers V2]} on 0,

[Date].[Date].[Date].members

on 1

from

[Adventure Works]

Interestingly, this performs even worse than the previous query (although I would have expected it to be better). So how can we write a query that returns in a reasonable amount of time?

I haven’t found a way to do this for a calculated measure defined on the server, to be used in a true ad hoc query environment like Excel (any suggestions welcome – please leave a comment if you can do it), but I have got a way of optimising this calculation for scenarios where you have control over the MDX being used, such as in SSRS.

Here’s the query:

with

set customerdates as

nonempty(

[Date].[Date].[Date].members

*

[Customer].[Customer].[Customer].members

, [Measures].[Internet Sales Amount])

set nondistinctcustomers as

generate(

customerdates,

{[Customer].[Customer].currentmember}, all)

member measures.customercountsum as

sum(null:[Date].[Date].currentmember, [Measures].[Customer Count])

member measures.[Returning Customers V3] as

count(

intersect(

subset(nondistinctcustomers

    , (measures.customercountsum, [Date].[Date].currentmember.prevmember)

    , [Measures].[Customer Count])

,

head(nondistinctcustomers

    , (measures.customercountsum, [Date].[Date].currentmember.prevmember))

)

)

select {measures.[Returning Customers V3]} on 0,

[Date].[Date].[Date].members

on 1

from

[Adventure Works]

On my laptop, this query executes in around 5 seconds on a cold cache. The reason it’s so much faster is also the reason it can’t be used in ad hoc queries – it uses named sets to find all the combinations of customer date needed by the query in one operation. Here’s a step-by-step explanation of how it works:

• First of all, the customerdates set gets a set of tuples containing every single combination of day and customer where a purchase was made, using a simple Nonempty().
• Next, the nondistinctcustomers set takes the customerdates set and removes the dates, so what we are left with is a list of customers. It’s not a list of distinct customers, however – a given customer may appear more than once. This still represents a list of the customers that bought something each day, it’s just that we no longer have any information about which day we’re looking at.
• The customercountsum measure allows us to take the list of customers in the nondistinctcustomers set and find out which customers bought something in any given day. It’s a running sum of the Customer Count measure. This is a distinct count measure, and usually you wouldn’t use the Sum() function on a distinct count, but it’s important we do here. How is it used? For example, let’s imagine we had just three days of data: on the first day we had three customers, on the second four customers and on the third five customers. That would result in the nondistinctcustomers set containing twelve (not necessarily distinct) customers. We can then use the running sum of a distinct count of customers to find out the index of the item in nondistinctcustomers that is the last customer in the list for each day. So on day two we would have a running sum of seven, and therefore the seventh item in nondistinctcustomers gives us the last customer in the list for that day.
• Finally, the Returning Customers V3 measure gives us the number of returning customers each day. It uses the customercountsum measure to find the subsets of the nondistinctcustomers set that represent the customers that bought on the current day and the customers that bought on all days up to yesterday, then uses the Intersect() function to find the returning customers.

I don’t usually like to blog about topics that I think other people have blogged about already, but despite the fact that Mosha blogged about this several years ago (in fact more than eight years ago, blimey) this particular problem comes up so often with my customers and on the MSDN Forum that I thought I should write something about it myself. So apologies if you know this already…

Here’s the problem description. If you define a calculated measure in MDX, that calculation will take place after the real measure values have all aggregated. For example, consider a super-simple cube with a Year dimension, two real measures called A and B and a calculated measure called [A * B] that returned the value of A multiplied by B. In a PivotTable you’d see the following result:

Note how the Grand Total for the [A * B] calculated measure is 12*16=192, and not 12+12+12+12=48. This is expected behaviour for calculated measures, and indeed the way you want your calculations to behave most of the time.

However, there are some scenarios where you want to do the calculation first and then aggregate up the result of that calculation; in our previous example that means you’d get 48 for the Grand Total instead. Currency conversion and weighted averages are common examples of calculations where this needs to happen. How can you handle this in MDX?

Let’s look at a slightly more complex example than the one above. In the following cube, based on Adventure Works data, I created a Date dimension that looks like this:

…and a Product dimension that looks like this:

I also created two measures on a fact table called A and B:

Now, let’s say that once again you want to calculate the value of A*B at the Date and Product granularity, and aggregate the result up. Probably the easiest way of handling this would be to do the calculation in the fact table, or in the DSV, and then bringing the result in as a new real measure. However this may not be possible with some types of calculation, or if the granularity that you want to do the calculation is not the same as the granularity of the fact table.

One way of approaching this in MDX would be to create a calculated measure like this:

CREATE MEMBER CURRENTCUBE.MEASURES.[CALC] AS
SUM(
DESCENDANTS([Date].[Calendar].CURRENTMEMBER, [Date].[Calendar].[Date])
*
DESCENDANTS([Product].[Category – Product].CURRENTMEMBER, [Product].[Category – Product].[Product])
, [Measures].[A] * [Measures].[B]);

The big problem with this approach (apart from the fact that it may break when you do a multi-select in certain client tools – but you could work around that) is that it is usually very, very slow indeed. Depending on the calculation, it may be unusably slow. So you need a different approach.

This is where scoped assignments come in. If you make a scoped assignment to a real measure, as opposed to a calculated measure, then the value of the assignment will aggregate up outside of the original scope. So, in this case, since you want the calculation to take place at the Date and Product granularity, if you scope on a real measure at that granularity the result of the calculation will aggregate up automatically.

The first step here is to create a new real (ie not calculated) measure for the calculation. This can be done in the DSV by creating a named calculation on your fact table which returns the value NULL:

You then need to create a new real measure on your measure group from this new named calculation:

In this example, I’ve left the AggregateFunction property of the measure to be the default of Sum, but you could use a different setting if you wanted a different type of aggregation. The next step is to process the cube, and once you’ve done that you’ll see a new measure that only returns the value 0:

Next, you need to create the scoped assignment on the Calculations tab of the Cube Editor. If you remember in my post last week about scoped assignments, I recommended avoiding writing scopes using user hierarchies; using only attribute hierarchies the scope statement becomes:

SCOPE([Measures].[A Multiplied By B]);
    SCOPE([Date].[Date].[Date].MEMBERS);
        SCOPE([Product].[Product].[Product].MEMBERS);
            THIS = [Measures].[A] * [Measures].[B];
        END SCOPE;
    END SCOPE;
END SCOPE;

One very important thing to notice: the sets I’ve used for scoping on the Dates and Products do not include the All Member: for example, [Date].[Date].[Date].MEMBERS. If you use a set that includes the All Member, such as [Date].[Date].MEMBERS, the calculation will not aggregate up correctly.

Here’s the result:

This is going to be much more efficient than the pure MDX calculated measure approach, though just how well the calculation performs will depend on the complexity of the calculation and the size of the area that you are scoping on.
